Product Details:
|
| Name: | Railway Locomotive Axle | Material: | LZ50, AAR Grade F, EA1N, IRS 16/95, And Etc. |
|---|---|---|---|
| Standard: | TB, AAR, UIC, EN, BS, IRS, JIS, KSR, GOST And Etc. | Test: | Chemical, Metallographic, Mechnical, UT, MT And Etc. |
| Certification: | ISO9001,ISO14001, OHSAS18001, AAR, IRIS, TSI | Process: | Cutting, Heating, Forging, Straightening, Rough And Semi-Finish Machining |
| High Light: | locomotive axle,train axle |
||
Railway Axle Locomotive Axle Train Axle Metro Axle Wagon Axle
AAR Axle GOST Axle TSI Axle
Description of Railway Locomotive Axle:
| Product Name | Railway Locomotive Axle |
| Wide Material | Axles wide range of raw material steel support LZ50, JZ45,AAR Grade F, EA1N, EA1T, EA4T, IRS 16/95, SFA60A, and etc. |
| Wide Standards | Axles confirm to every recognized international quality standard: TB/T 2945, AAR M-101, UIC 811-1, EN 13261, BS 5892 PART 1, IRS 16/95, JIS E 4502, KSR 9220, GOST 31334 and other customer's requirement. |
| Size |
According to customers' drawings. We can produce all kinds of truck gauges Railway Locomotive Axle. The axle length range from 1200 to 2800mm |
| Test |
We can do all the tests according to different standards. Such as: Chemical analysis, Metallographic, Mechnical analysis, Ultrasonic testing, Magnetic testing, Impact testing, Hardness testing, Surface quality and dimensions. |
| Certifications | ISO9001,ISO14001, OHSAS18001, AAR, IRIS, TSI |
Locomotive Axle
| Parameter | |
| Axle length | 1879.6mm |
| Journal Diameter | 144.56mm |
| Wheel seat Diameter | 206.66mm |
| Gear seat Diameter | 209.55mm |
| Bearing center distance | 1625.6mm |
Manufacturing Process:
Billet Steel Review→ Cutting→ Heating→ Forging→ Straightening→ Heat Treatment→ Sampling Test→ Rough Machining→ Semi-Finish Machining→Ultrasonic Inspection→ Finish Machining→ Grinding→ Magnetic Particle Testing→ Packing
| The tests we conduct to ensure best quality | |||
| Chemical Analysis | Metallographic | Mechanical Analysis | Ultrasonic Testing |
| Magnetic Testing | Impact Testing | Hardness Testing | Surface Quality |
| Diemension Checks(CMM) | Customers' acceptance check or third party check | ||
