Product Details:
|
| Name: | Railway Type F Axle | Rail Gauge: | 1435mm |
|---|---|---|---|
| Axle Load: | 32.4t | Axle Length: | 2276.475mm |
| Bearing Center Distance: | 2006.6mm | Material: | LZ50, AAT Grade F, EA1N, EA4T, IRS 16/95 |
| High Light: | train axle,wagon axle |
||
Railway Axle Class F Axle For Freight Wagon Railroad Wagon Axles Train Axle Bogie Axle AAR / GOST / TSI Axle Standard Gauge Wagon Axle
Description of Railway Axle:
Freight Wagon Axle of Type F Standard Gauge
| Parameter | |
| Axle load | 32.4t |
| Rail Gauge | 1435mm |
| Axle length | 2276.475mm |
| Journal Diameter | 157.239mm |
| Wheel seat Diameter | 222.25mm |
| Bearing center distance | 2006.6mm |
| Standards | TB/T 2945, AAR M-101, UIC 811-1, EN 13261, BS 5892 PART 1, IRS 16/95, JIS E 4502, KSR 9220, GOST 31334, AS 7515 and other customer's requirement. |
| MATERIAL | STANDARD | CHEMICAL COMPOSITION | |||||||||
| C | Mn | Si | P | S | Cr | Ni | Mo | Cu | V | ||
| EA1N | EN13261 | ≤0.4 | ≤ 1.2 | ≤ 0.5 | ≤0.02 | ≤0.02 | ≤0.30 | ≤0.30 | ≤ 0.08 | ≤ 0.30 | ≤ 0.06 |
| EA1T | |||||||||||
| A1N | BS5892-1 | ≤0.4 | ≤ 1.2 | ≤ 0.5 | ≤0.04 | ≤0.04 | ≤0.30 | ≤0.30 | ≤ 0.08 | ≤ 0.30 | ≤ 0.05 |
| A1T | |||||||||||
| A1(N) | UIC811-1 | ≤0.37 | ≤ 1.12 | ≤ 0.46 | ≤0.04 | ≤0.04 | ≤0.30 | ≤0.30 | ≤ 0.05 | ≤ 0.30 | ≤ 0.05 |
| A1(T) | |||||||||||
| Grade F | AAR M-101 | 0.45-0.59 | 0.7-1 | 0.15-0.4 | ≤0.045 | ≤0.05 | 0.02-0.08 | ||||
| N | IRS:R-16/95 | ≤0.37 | ≤1.12 | 0.15-0.46 | ≤0.04 | ≤ 0.04 | ≤ 0.30 | ≤ 0.30 | ≤0.05 | ≤ 0.30 | ≤ 0.05 |
| T | |||||||||||
| LZ50 | TB/T 2945 | 0.47-0.57 | 0.6-0.9 | 0.17-0.40 | ≤ 0.03 | ≤ 0.03 | ≤ 0.30 | ≤0.30 | ≤ 0.25 | ||
| SFA60A | JIS E 4502-1 | ≤0.035 | ≤0.04 | ||||||||
| SFA60B | JIS E 4502-1 | ≤0.045 | ≤0.045 | ||||||||
