Product Details:
|
| Name: | Control Connector Operating | Material: | Cast Aluminum(connect Shell) 、Copper Alloy(contact)、PC(insulating Board) |
|---|---|---|---|
| Voltage Rating: | DC110V | Current Rating: | 15A |
| Temperature Rise: | ＜60K | Contact Resistance: | ≤2mΩ |
| Insulation Resistance: | ≥500MΩ | Dielectric Strenght: | 1500V/1min, 50Hz |
| Protection Level: | IP65 |
Railway Control Connector Operating Manual/KC2-50D
Introduction
KC2-50D control connector is designed and manufactured according to Vehicle and Electric
Communication(Control)Couplers for Locomotives and Rolling (GB/T 25022-2010).This
connector consists of plugs and sockets. There are 50 pairs of contact pairs.
KC2-50D type passenger car control connector is used for signal control of new type passenger car of
railway. It is one of series products of passenger car control connectors researched and developed by our company.
Main performance and technical parameters
Voltage Rating: DC110V
Current Rating: 15A
Temperature Rise: ＜60K
Contact Resistance:≤2mΩ
Insulation Resistance:≥500MΩ
Dielectric strenght:1500V/1min, 50Hz
Protection level:IP65
Mechanical life:＞1500 times
material: Cast aluminum(connect shell) ,Copper alloy(contact),PC(insulating board)
Service Conditions
Ambient temperature:－50℃~+70℃
Relative humidity:Not more than 93%
(Monthly average minimum temperature is 25°C in this month.)
Atmospheric pressure:≥70KPa
Altitude:Not more than 2500m
Packaging,Transportation
Plugs and sockets must be packed and transported under separation status.
